R8249-01 R8249-01A Touch Panel Replacement

categories	HMI Touch Screen Panel
Model	R8249-01 R8249-01A
Warranty	365 Days
Supply	R8249-01 R8249-01A HMI Touch Glass
FOB port	Guangzhou, Shenzhen, Hongkong
Terms of Payment	Western Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Update Time	2026-02-05 17:30:59

{{item.condition_name}}

SKU {{item.sku}}

{{item.symbol}} {{item.price}}

Wholesale Price

Request a Quote

Leading Time{{selectedConditionObj.leading}}

{{nameObj.name}}{{nameObj.selectedValue}}

Shipping

Detail Information

Contact Best Price

Specifications:

Part Number :	R8249-01 R8249-01A
Display Type:	TFT
Resolution:	320x240 pixel
Backlight:	LED
Warranty:	365 Days

Input Power:	24VDC (+10%, -15%)
Touch Screen:	Resistive
Operating Temperature:	0 to 45 °C
Touch Size:	5.7"

FAQ:

Question: What are the R8249-01 R8249-01A Touch Panel HMI installation procedures?

Answer: Place the four fixing brackets on the longer side near the corners, as shown in figure . Screw each fixing screw until the plastic or aluminium bezel corner get in contact with the panel.

Question: How to cleaning R8249-01 R8249-01A IHM faceplates?

Answer: The equipment must be cleaned only with a soft cloth and neutral soap product. Do not use solvents.

Common misspellings:

R249-01

R8249-1A

R8249-01

R8249-10A

R8249-0L

R8249-01A

R8249-o1

R8249--01
