6AG1055-4MH08-2BA0 Siemens LOGO! TDE Text Display

categories	Siemens TD Series
Brand	SIEMENS
Model	6AG1055-4MH08-2BA0
Warranty	6 Months
Product Line	Siemens LOGO! TDE
Supply	Outer Covering LCD Display
FOB port	Guangzhou, Shenzhen, Hongkong
Terms of Payment	Western Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Update Time	2026-01-30 20:51:28

{{item.condition_name}}

SKU {{item.sku}}

{{item.symbol}} {{item.price}}

Wholesale Price

Request a Quote

Leading Time{{selectedConditionObj.leading}}

{{nameObj.name}}{{nameObj.selectedValue}}

Shipping

Detail Information

Contact Best Price

Specifications:

Part Number :	6AG1055-4MH08-2BA0
Number of lines:	6
Number of lines:	6
Warranty:	12-Months Warranty
Product Line:	Siemens LOGO! TDE

Rated value (DC):	24 V
Special characters:	14
Membrane keyboard:	Yes
Keyboard fonts:	US English
Controllable background colors:	3, white, orange, red

Related BB Teach Pendant Part No.:

6AG1055-4MH08-2BA0	Description	Inventory status
6AG1055-4MH00-7BA1	Siemens SIPLUS LOGO! TDE Terminal Keypad LCD Display Plastic Case Cover	In Stock
6AG1055-4MH08-2BA0	Siemens SIMATIC TED Keyboard Membrane Plastic Shell LCD Display Screen	In Stock
6AG1055-4MH08-2BA1	Siemens LOGO! TDE Membrane Keypad Enclosure LCD Display Replacement	Available Now
6ED1055-4MH00-0BA1	New LOGO! TDE Text Display Keypad Plastic Case LCD Display Panel Repair	Available Now
6ED1055-4MH08-0BA0	New LOGO! TDE Text Display Membrane Keypad Keyboard LCD Screen Housing	In Stock
6ED1055-4MH08-0BA1	Siemens LOGO! TDE Membrane Keypad Switch Plastic Cover LCD Screen Repair	Available Now

6AG1055-4MH08-2BA0 Siemens LOGO! TDE Text Display PDF Download:

SIMATIC TD Series

Siemens 6AG1055-4MH00-7BA1 Datasheet

SIMATIC 6AG1055-4MH00-2BA0 Datasheet

Siemens LOGO! Logic Modules 2019 Manual

Siemens Simatic Factory Automation SIMATIC LOGO! ..0BA6

FAQ:

Question: How to program with 6AG1055-4MH08-2BA0 Siemens LOGO! TDE?

Answer: The configuration data of the LOGO!TDE is stored in the CPU of the S7-200. The message texts and theconfiguration parameters are created with the STEP 7-Micro/WIN V4 SP6 programming software. Additionalparameterization software is not required. The operating front design is configured with the Keypad Designer(component part of STEP 7-Micro/WIN V4 SP6).Special data areas are reserved in the CPU of the S7-200 for data exchange with the LOGO!TDE. The LOGO!TDE accesses each of the required functions of the CPU direct via these data areas. User-friendly parameterizationtakes place via a dedicated LOGO!TDE Wizard in STEP 7-Micro/WIN V4 SP6.

Question: Which is the design of Siemens LOGO! TDE?

Answer: The LOGO!TDE is connected to the S7-200 using the supplied connecting cable. A separate power supply is not required.It is also possible to connect several LOGO!TDE to one S7-200.

Question: What is the 6AG1055-4MH08-2BA0 Siemens LOGO! TDE membrane switch and shell HMI parts price?

Answer: Submit a fast quote, send Kernfix an email for best price.
