2711P-T15C6D7

FAQ:

Question: What is the 2711P-K15C6D7 Panelview Plus 1500 HMI parts price?

Answer: Submit a fast quote, send Kernfix an email for best price.

Question: How to replace 2711P-T15C6D7 Display Module Bezel?

Answer: 1. Make sure new bezel is free of lint and marks before attaching.2. Attach the following connectors. The number of connectors varies by model.• IrDa connector• Function Key connector3. Place the back of the Display Module over the new bezel. Be careful not to pinch any of the cables.Allow the Touch Screen connector to extend out of the access opening.4. Attach Touch Screen connector.5. Replace the sealing gasket.6. Attach screws that secure Display Module to bezel and tighten to a torque of 1.35 - 1.58 N•m (12-14 in-lb).7. On touch screen terminals, re-attach the small metal plate to the back of the Display Module using 2 screws.

Question: How to edit the 2711P-T15C6D7 device address of the logic controller?

Answer: 1. From the RSLinx Configuration screen, select a device node.2. Select the Edit Device button.A screen opens showing the name of the device and its current node address.3. To modify the device address, press the Device Address button.The Input Panel opens showing the current address.4. Using the Input Panel, modify the address and then select the Enter button.

Question: If the terminal display is dim or unreadable, what should we do?

Answer: • Check the brightness setting of the display. From Configuration mode on the terminal, access Terminal Settings>Display Intensity.• Check the Screen Saver settings. The backlight may be turning off or dimming the display unexpectedly. From Configuration mode on the terminal, access Terminal Settings>Display>Screen Saver.
