Question: How to connect the DTAM Plus terminal 2707-V40P1R to an RS-485 device?

Answer: 1. Make sure that the power to the DTAM Plus is off.2. Use the proper cabling to connect the DTAM Plus communications port to the port of the controller (PLC-5 channel 0 or SLC 5/03 or SLC 5/04 RS-232 port).• Use cable, Catalog No. 2707-NC4 for PLC-5 channel 0 RS-422 connection• Use cable, Catalog No. 2707-NC5 for PLC-5 channel 0 RS-232 connection. The 2707-NC5 cable converts the signals from the RS-485 port to RS-232 levels.• Use cable, Catalog No. 1747-CP3 for SLC 5/03, 5/04, 5/05 port connectionIf you need to make your own cable, refer to the connection diagrams in Appendix B. The maximum cable length is 200 feet (60.8 meters). Important: The DH-485 network cable requires proper shielding, grounding, and termination. Refer to Data Highway / Data Highway Plus / Data Highway-485 Cable Installation Manual (Pub. No. 1770-6.2.2).3. The DH-485 connectors are not electrically isolated. If electrical isolation is required, use Link Couplers (Catalog No. 1747-AIC) shown above.4. Make sure that the communication parameters of the DTAM Plus terminal match the host device. 5. Apply power and verify that communications are established.

Question: How to reset the Rockwell Allen Bradley DTAM Plus 2707-V40P1R?

Answer: 1. From the Function Menu, select Reset [4].This screen appears:2. Press [Y] on the keypad to initiate the reset. The DTAM Plus resets. This has the same effect as turning the power off and on. The DTAM Plus performs the self diagnostic tests and powerup displays as described in the previous section.
