Hakko V712S Touchscreen V712SD Film Housing Repair

FAQ:

Question: What is the procedure of V712S V712SD Battery Mounting?

Answer: 1. Turn the unit off.2. Slide the battery holder cover in the direction of the arrow as shown in the left illustration below to open it.3. Check that the battery is securely attached to the backside of the cover, and connect the battery connector.4. Close the battery holder cover.5. Enter a date five years from now for “Battery replacement” on the sticker on the battery holder.* The battery status is output to the internal memory $s167 of the V7 series. If the battery voltage drops before five years has elapsed, replace the battery immediately.6. Turn on the power to the V7 unit and check that the battery is correctly mounted on the Main Menu screen.When the battery is not connected, the [SRAM/Clock] switch blinks and the message “Battery not set” is displayed at the bottom left corner.When the battery is correctly connected, the [SRAM/Clock] switch goes out and the message is cleared.When the battery voltage has dropped, the message “Brownout Battery” is displayed.

Question: How to check V712S V712SD Print?

Answer: 1. Connect the V7 unit to the printer.2. Press the [Printer Check] switch. The test is successful when a test page is printed out without problem.
